SCS5041TQZSX??Model technical parameters | |||
Name: | SCS5041TQZSX | Exterior size(mm): | 5998×2300×2460 |
Chassis: | SX1040GP5 | Container size(mm): | ×× |
Total weight :(kg) | 4495 | Approach angle/ Departure angle(° ) | 17/12 |
Payload:(kg) | Front suspension/rear suspension(mm): | 1200/1538 | |
Kerb Mass:(kg) | 3750(Kg) | Max Speed(km/h): | 80,90 |
Chassis parameters | |||
Chassis: | SX1040GP5 | Axle weight: | 1500/2995 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3260,3300,3360 | Fronttread(mm): | 1670 |
Max people in cab: | 3 | Rear tread(mm): | 1525 |
Number of tires: | 6 | Number of spring axle: | 7/10+3,7/9+7,9/11+8 |
Tire Type: | 7.00-16LT 8PR,7.00R16LT 8PR,7.50-16LT 6PR,7.50R16LT 6PR | ||
introduction: | 该车用途为道路故障车辆、城市违章车辆及抢险救援等;主要装置为托臂、取力器、液压油缸组成。随底盘选装驾驶室.选装摆臂平板装置和后拦板.托举质量:550kg;侧防护材料碳钢/Q235B,螺栓加焊接连接;后防护由专用装置替代,下边缘离地高470mm。ABS型号:ZQFB-V,厂家:西安正昌电子有限责任公司. |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISF3.8s5141 WP3Q130E50 YN38CRE1 D25TCIE3 D25TCIE1 WP3.7Q130E50 |
北京福田康明斯发动机有限公司 潍柴动力扬州柴油机有限责任公司 昆明云内动力股份有限公司 昆明云内动力股份有限公司 昆明云内动力股份有限公司 潍柴动力扬州柴油机有限责任公司 |
3760 2970 3760 2499 2499 3660 |
105 96 95 92 105 96 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
