SCS5043TQZCAL??Model technical parameters | |||
Name: | SCS5043TQZCAL | Exterior size(mm): | 5998×2300×2380 |
Chassis: | CAL1041DCRE5 | Container size(mm): | ×× |
Total weight :(kg) | 4495 | Approach angle/ Departure angle(° ) | 20/13 |
Payload:(kg) | Front suspension/rear suspension(mm): | 1110/1580 | |
Kerb Mass:(kg) | 3990(Kg) | Max Speed(km/h): | 90 |
Chassis parameters | |||
Chassis: | CAL1041DCRE5 | Axle weight: | 1615/2880 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3308 | Fronttread(mm): | 1665 |
Max people in cab: | 3 | Rear tread(mm): | 1525,1590 |
Number of tires: | 6 | Number of spring axle: | 11/8+6,7/7+5 |
Tire Type: | 7.00-16 8PR,7.00R16 8PR,7.50-16 6PR,7.50R16 6PR | ||
introduction: | 随底盘选装驾驶室.选装摆臂平板装置和后拦板.托举质量:310kg;侧防护材料碳钢/Q235B,螺栓连接;后防护由专用装置替代。ABS控制器型号/厂家:ABS 8/克诺尔制动设备(上海)有限公司。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
CY4BK451 YN33CRE1 JE493ZLQ5 |
东风朝阳朝柴动力有限公司 昆明云内动力股份有限公司 江西五十铃发动机有限公司 |
3707 3298 2771 |
86 85 85 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
