CLW5080TQZB5??Model technical parameters | |||
Name: | CLW5080TQZB5 | Exterior size(mm): | 7390×2300×2500 |
Chassis: | BJ5089XXY-FA | Container size(mm): | ×× |
Total weight :(kg) | 8280 | Approach angle/ Departure angle(° ) | 21/14 |
Payload:(kg) | Front suspension/rear suspension(mm): | 1120/2470 | |
Kerb Mass:(kg) | 4820(Kg) | Max Speed(km/h): | 95 |
Chassis parameters | |||
Chassis: | BJ5089XXY-FA | Axle weight: | 2840/5440 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3360,3800 | Fronttread(mm): | 1730,1685,1665 |
Max people in cab: | 3 | Rear tread(mm): | 1590,1615 |
Number of tires: | 6 | Number of spring axle: | 3+1/6+7,9/11+7 |
Tire Type: | 7.50-16 7.50R16 8.25-16,8.25R16 14PR | ||
introduction: | 托举质量:3265kg。侧防护与底盘副梁间采用焊接联接,后部装有托臂装置,故可豁免。随底盘选装驾驶室.ABS厂家:威伯科汽车控制系统()有限公司,型号:44600XXXX0. |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISF3.8s5141 ISF3.8s5154 ISF3.8E6154 |
北京福田康明斯发动机有限公司 北京福田康明斯发动机有限公司 北京福田康明斯发动机有限公司 |
3760 3760 3760 |
105 115 115 |
other parameters |
Introduction: |
more Picture: |
