CLW5060JGKZ4 - Suizhou Liyuan Trading Co., Ltd
  • Phone:Mr zhou +86 15997916929
  • Add time:2011-07-08 11:15:17
  • Hits:823
for the convenience of users to mention cars, our company agents to carry out car door-to-door delivery service.
the above price of vehicles, models, such as configuration and the color difference, please in order to prevail.
.
CLW5060JGKZ4 Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
CLW5060JGKZ4??Model technical parameters
Name: CLW5060JGKZ4 Exterior size(mm): 7300×2000×3050
Chassis: HFC1073R83K1C3 Container size(mm): ××
Total weight :(kg) 6300 Approach angle/ Departure angle(° ) 24/14
Payload:(kg) Front suspension/rear suspension(mm): 1105/2035
Kerb Mass:(kg) 5975(Kg) Max Speed(km/h): 90
Chassis parameters
Chassis: HFC1073R83K1C3 Axle weight: 2230/4070
Number of axles: 2 Fuel Type: Diesel fuel
Wheelbase(mm): 3360 Fronttread(mm): 1440
Max people in cab: 2+3 Rear tread(mm): 1425
Number of tires: 6 Number of spring axle: 7/4+5,8/4+5
Tire Type: 7.00R16 14PR,7.00-16 14PR
introduction: 该车吊臂前伸为800mm。防护材料:Q235A碳钢,连接方式:左右侧面及后下部防护均采用焊接连接,后部防护断面尺寸(mm):120×50,后部防护离地高度(mm):480。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
HFC4DA1-2C 安徽江淮汽车股份有限公司 2771 88
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
